Cablenet CNL 8Port 10/100/1000T Managed Switch
|
In Stock
Call us for price confirmation
+49 7251 941 3000
All items are duty-free in the EU. Business clients having EU-VAT number do not Pay VAT
Management features
Reset button
Yes
Multicast support
Yes
Traffic classification
Yes
ARP inspection
Yes
Switch type
Managed
Web-based management
Yes
System event log
Yes
Quality of Service (QoS) support
Yes
MIB support
RFC 1213 MIB-II, RFC 1215, RFC 1493, RFC 2674, RFC 2737, RFC 2819 RMON (1, 2, 3, 9), RFC 2863, RFC 3635
Ports & interfaces
Terminal block port
Yes
Copper ethernet cabling technology
10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-T
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power connector
DC-in jack
Network
IGMP snooping
Yes
Copper ethernet cabling technology
10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-T
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex
Yes
VLAN support
Yes
Spanning tree protocol
Yes
Rate limiting
Yes
Port mirroring
Yes
Number of VLANs
4094
Link aggregation
Yes
Broadcast storm control
Yes
Auto MDI/MDI-X
Yes
10G support
No
Virtual LAN features
Private VLAN, Tagged VLAN, Protocol-based VLAN
Virtual LAN features
VLAN support
Yes
Number of VLANs
4094
Virtual LAN features
Private VLAN, Tagged VLAN, Protocol-based VLAN
Data transmission
Number of multicast groups filtered
256
Number of VLANs
4094
Jumbo frames
10000
Throughput
11.9 Mpps
Packet buffer memory
4.1 MB
MAC address table
8000 entries
Switching capacity
16 Gbit/s
Store-and-forward
Yes
Number of trunks
4
Jumbo frames support
Yes
Performance
Packet buffer memory
4.1 MB
Stackable
No
Firmware upgradeable
Yes
Harmonized System (HS) code
85176990
Power
Power connector
DC-in jack
Power consumption (max)
152 W
Power protection features
Overdischarge
Input voltage
48 - 56 V
Input current
3:00 AM
Technical details
Product colour
Black
Stackable
No
Housing material
Metal
Firmware upgradeable
Yes
Rack mounting
No
Power over Ethernet (PoE)
Power protection features
Overdischarge
Power over Ethernet (PoE) voltage range
50 - 56 V
Power over Ethernet (PoE) power per port
36 W
Power over Ethernet plus (PoE+) ports quantity
4
Total Power over Ethernet (PoE) budget
144 W
Power over Ethernet (PoE)
Yes
Security
IP-MAC-Port binding
Yes
BPDU filtering/protection
Yes
Authentication
Port-based authentication
SSH/SSL support
Yes
Security algorithms
802.1x RADIUS, SNMP, SSH
MAC address filtering
Yes
IGMP snooping
Yes
Access Control List (ACL)
Yes
Multicast features
Number of multicast groups filtered
256
Multicast support
Yes
Protocols
Supported network protocols
IPv6, IPv4
Certificates
Certification
FCC 15 A, CE, IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6
Memory
Packet buffer memory
4.1 MB
Design
Wall mountable
Yes
International Protection (IP) code
IP30
Reset button
Yes
DIN rail mounting
Yes
Product colour
Black
Stackable
No
LED indicators
Activity, Link, PoE, Power
Housing material
Metal
Certification
FCC 15 A, CE, IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6
Rack mounting
No
Indication
LED indicators
Activity, Link, PoE, Power
Operational conditions
Storage temperature (T-T)
-40 - 85 °C
Storage relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-40 - 75 °C
Operating relative humidity (H-H)
5 - 95%
Heat dissipation
519 BTU/h
Weight & dimensions
Width
148 mm
Depth
25 mm
Height
134 mm
Weight
625 g
Packaging data
Terminal block included
Yes
Wall mounting kit
Yes
User guide
Yes
Other features
Terminal block port
Yes
Input voltage
48 - 56 V
Packaging content
Terminal block included
Yes
Wall mounting kit
Yes
User guide
Yes
