iiyama TW1623AS-B1P Signage Display Interactive flat panel 39.6 cm (15.6") Wi-Fi 450 cd/m² Double F
|
In Stock
Call us for price confirmation
+49 7251 941 3000
All items are duty-free in the EU. Business clients having EU-VAT number do not Pay VAT
Display
Panel type
IPS
Display number of colours
16.7 million colours
Number of simultaneous touchpoints
10
Touchscreen
Yes
Active display area (W x H)
344.2 x 193.6 mm
Display diagonal
39.6 cm (15.6")
Display resolution
1920 x 1080 pixels
Display brightness
450 cd/m²
HD type
Double Full HD
Response time
30 ms
Contrast ratio (typical)
1000:01:00
Viewing angle, horizontal
170°
Viewing angle, vertical
170°
Pixel pitch
0.17925 x 0.17925 mm
Native aspect ratio
16:09
Touchscreen technology
Projected capacitive system
Surface hardness
6H
Multi-touch
Yes
Glass thickness
1.8 mm
Ports & interfaces
USB port
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi
Yes
Microphone in
Yes
Compatible memory cards
SD
Card reader integrated
Yes
Ethernet LAN
Yes
HDMI ports quantity
1
USB version
2
USB ports quantity
3
Audio
Number of built-in speakers
2
RMS rated power
4 W
Built-in speaker(s)
Yes
Design
Product design
Interactive flat panel
Placement supported
Indoor
Orientation
Horizontal/Vertical
Product colour
Black
Panel mounting interface
100 x 100 mm
Certification
CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
VESA mounting
Yes
Fingerprint resistant
Yes
Performance
Purpose
Commercial
Operating hours (hours/days)
24/7
On Screen Display (OSD)
Yes
Wi-Fi
Yes
Power
Power consumption (off)
0.3 W
Power consumption (typical)
24 W
Power consumption (standby)
0.5 W
Computer system
Computer system
Yes
Processor cores
4
Processor family
ARM Rockchip
Processor model
RK3568
Processor frequency
2 GHz
Operating system installed
Android
Internal memory
4 GB
Internal storage capacity
32 GB
Processor manufacturer
Rockchip
Built-in processor
Yes
Processor architecture
ARM Cortex-A55
Operating system version
13
Weight & dimensions
Display width
387 mm
Display depth
30.5 mm
Display height
244 mm
Display weight
1.5 kg
Packaging data
Package width
477 mm
Package depth
75 mm
Package height
295 mm
Package volume
2400 cm³
Packaging content
Power adapter included
Yes
Certificates
Certification
CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Technical details
VESA mounting
Yes
Panel type
IPS
Number of simultaneous touchpoints
10
Thin Client
Processor family
ARM Rockchip
Processor model
RK3568
Processor frequency
2 GHz
Operating system installed
Android
Internal memory
4 GB
Internal storage capacity
32 GB
Other features
Panel type
IPS
Number of simultaneous touchpoints
10
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi
Yes
Microphone in
Yes
Compatible memory cards
SD
Card reader integrated
Yes
Bluetooth version
5.2
Bluetooth
Yes
Audio input
Mini Jack
iiyama TW1623AS-B1P Signage Display Interactive flat panel 39.6 cm (15.6") Wi-Fi 450 cd/m² Double F
| Length | 7.5 cm |
| Width | 47.7 cm |
| Height | 29.5 cm |
| Weight | 1.000000 kgs |
