HPE Aruba JL254A New

Device Type

Switch - 48 ports - L3 - Managed - stackable

Enclosure Type

Rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)

Performance

Capacity

Jumbo frame size: 9220 IPv4 routing table entries: 10000 IPv6 routing table entries: 5000

MAC Address Table Size

32K entries

Routing Protocol

OSPF, RIP, RIP-1, RIP-2, BGP, IGMPv2, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLD, CIDR

Remote Management Protocol

SNMP 1, SNMP 2, RMON 1, SNMP, Telnet, SNMP 3, SNMP 2c, SSH, SSH-2, CLI, XRMON

Encryption Algorithm

MD5, SSL

Authentication Method

RADIUS, PAP, CHAP, TACACS, TACACS+

Features

Flow control, full duplex capability, DHCP support, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, DiffServ support, IPv6 support, SNTP support, sFlow, Spanning Tree Protocol (STP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, DHCP server, STP Root Guard, Uni-Directional Link Detection (UDLD), LLDP support, Link Aggregation Control Protocol (LACP), Management Information Base (MIB), MAC address lockout, dynamic ARP protection, DHCP protection, Dynamic VLAN Support (GVRP), Multiple VLAN Registration Protocol (MVRP), Neighbor Discovery Protocol (NDP), Class of Service (CoS), Type of Service (ToS), OpenFlow support, CPU protection, Internet Control Message Protocol (ICMP), ICMP Router Discovery Protocol (IRDP), Virtual Extensible LAN (VXLAN), Management Information Base (MIB) II

Compliant Standards

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX

Processor

1 x ARM Cortex-A9: 1.016 GHz

RAM

1 GB DDR3 SDRAM

Flash Memory

4 GB

Interfaces

48 x 1000Base-T RJ-45 4 x Gigabit / 10Gbit LAN SFP+ 1 x serial (console)

Expansion Slots

1 (total) / 1 (free) x Expansion Slot

Installed Modules Qty (Max)

0 (installed) / 4 (max)

Power Device

Internal power supply

Installed Qty

1

Voltage Required

AC 120/230 V

Power Consumption Operational

46.6 Watt

80 PLUS Certification

80 PLUS Silver

Included Accessories

Mounting screws, 4 mounting ears, 4 bumper feet, cable tie

Compliant Standards

CISPR 22 Class A, CISPR 24, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, ICES-003 Class A, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1-07 Second Edition, VCCI Class A, IEC 60825-1:2007, CNS 13438, EN 55024:2010, EN 55022:2010, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 60825-1:2007, FCC CFR47 Part 15 A, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013

Software Included

Command Line Interface (CLI), HP Web browser, HP Intelligent Management Center

Width

44.25 cm

Depth

24.63 cm

Height

4.39 cm

Weight

3.1 kg

Service & Support

Limited warranty - lifetime

Min Operating Temperature

Max Operating Temperature

Humidity Range Operating

15 - 95% (non-condensing)

Min Storage Temperature

Max Storage Temperature

Humidity Range Storage

15 - 90% (non-condensing)
