ATEN 2P 4K DP Dual Display Mini-Matrix
|
In Stock
Call us for price confirmation
+49 7251 941 3000
All items are duty-free in the EU. Business clients having EU-VAT number do not Pay VAT
Ports & interfaces
Console ports
3.5mm headphone, 3.5mm mic, HDMI, USB A
Number of microphone inputs
4
DisplayPorts quantity
4
DisplayPort version
1.2
Number of computers controlled
2
Keyboard port type
USB
Mouse port type
USB
Video port type
DisplayPort
Audio connections
Yes
Headphone outputs
4
DC-in jack
Yes
USB hub
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity
2
Console HDMI ports quantity
2
HDCP
Yes
Performance
HDCP
Yes
Data transfer rate (max)
5 Gbit/s
HD type
4K Ultra HD
Maximum resolution
4096 x 2160 pixels
Scan interval
1,3,4,5,8,10,15,20,25,30,35,40,45,50,55,60,70,80,90,99 s
Technical details
Product colour
Black
Scan interval
1,3,4,5,8,10,15,20,25,30,35,40,45,50,55,60,70,80,90,99 s
Push button
Yes
LED indicators
Yes
Hot keys
Yes
USB hub
Yes
Design
Product colour
Black
Push button
Yes
LED indicators
Yes
Hot keys
Yes
Housing material
Metal
Display
Built-in display
No
Power
Power source
DC
Power consumption (typical)
11.58 W
Input voltage
12 V
Video
HD type
4K Ultra HD
Maximum resolution
4096 x 2160 pixels
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Weight & dimensions
Width
71.8 mm
Depth
260 mm
Height
42.5 mm
Weight
640 g
Other features
Push button
Yes
Hot keys
Yes
ATEN 2P 4K DP Dual Display Mini-Matrix
| Length | 26 cm |
| Width | 7.18 cm |
| Height | 4.25 cm |
| Weight | 0.640000 kgs |
